| FRAME | eONE-SIXTY CF III; MAT carbon; 160 STR; 29” x 2,6” max. WHS; 148x12 AST; intube; max. 630 Wh |
| SHOCK | Rock Shox Super Deluxe Select |
| FORK | Domain Gold RC E-MTB; Air; 170 STR; Tapered; 44mm fork offset; 29x3.0" max WHS |
| BRAKE - FRONT | Sram DB8 Stealth; 4 piston |
| BRAKE - REAR | Sram DB8 stealth; 4 piston |
| ROTOR - FRONT | Sram HS2; 220mm |
| ROTOR - REAR | Sram HS2; 200mm |
| CHAIN | Sram NX Eagle |
| CHAINWHEEL | Sram XX Eagle Transmission E-MTB for Steps; 36 ATC |
| CRANK/SIZE | Shimano FC-EM600; 165 mm all sizes; |
| BB SET | included |
| DERA - FRONT | |
| DERA - REAR | Sram NX Eagle |
| FREEWHEEL | Sram CS PG1230 EAGLE 11-50T |
| PEDAL | VP VPE-527 |
| GRIP | MERIDA EXPERT EC |
| H-BAR | MERIDA EXPERT eTR; 780 WHB; XS,S 20RHB ; M,L,XL 30RHB |
| H-B STEM | MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount |
| STEM/SIZE | 40 mm all sizes |
| HEAD SET | Acros ICR MERIDA INTEGRATED neck w/ Blocklock |
| HUB - FRONT | Novatec SL-ELITE D041SB-B15; 110x15 WHF; 32 SPH; 6 bolt |
| HUB - REAR | Novatec SL-TEAM D462SB-S3S-B12-11S; 148x12 WHR; 32 SPH; 6 bolt |
| AXLE - FRONT | |
| AXLE - REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA EXPERT TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5" |
| RIM TAPE | |
| SADDLE | MERIDA COMP SL; V-mount; incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XS: 125 SPT - S: 150 SPT - M/L: 200 SPT - XL: 230 SPT |
| SHIFTER - FRONT | Limotech RM10 (For SRAM MMX) |
| SHIFTER - REAR | Sram NX Eagle Single Click |
| INNER TUBE | 27.5*2.3/3.0(2.4/2.8) F.V 48L THIN(1MM) |
| TYRE - FRONT | Maxxis Assegai; 29x2.5 "; fold; TR EXO+ 3C MaxxGrip |
| TYRE - REAR | Maxxis DHR II; 27.5x2.4 "; fold; 3C DD TR MaxxTerra |
| BOTTLE CAGE | |
| CARRIER | |
| FENDER | EOF-204 |
| KICKSTAND | |
| LIGHT - FRONT | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount |
| LIGHT - REAR | USB REAR Light CG-214RG |
| FRAME LOCK | |
| DRIVE UNIT | Shimano EP801; 85Nm |
| DRIVE COVER | CR-026 + CR-027 |
| BATTERY | Trendpower TPS-C15-58SD; 600Wh integrated |
| BATTERY CHARGER | Trendpower EU Smart Charger; 4A |
| BATTERY LOCK | |
| DISPLAY | Shimano SC-EM800 |
