| FRAME | eFLOAT CC LITE II; aluminium; 29"x2.4" with fender max. wheelsize; 148x12mm axle standard; intube battery |
| FRAME SIZE | S (380) / M (430) / L (480) / XL (530) |
| FORK | SR Suntour XCM34-Boost Coil; 120mm travel; 29x2.4" max wheelsize |
| REAR SHOCK | |
| DRIVE UNIT | Bosch Performance Line CX |
| BATTERY | Bosch PowerTube 600 Wh |
| BATTERY CHARGER | Bosch 2A Charger (220-240V) |
| DISPLAY | Bosch Purion 200 |
| MODE SWITCH | |
| REAR DERAILLEUR | Shimano Cues U4000 GS |
| SHIFTERS | Shimano Cues U4000-9 |
| DROPPER POST LEVER | |
| BRAKES | Shimano MT200 2 piston |
| ROTORS | Shimano RT10 180mm front and rear |
| CHAINRING | FSA Direct Mount Steel Chainring; 38T |
| CRANK | FSA CK-220 Gen3 E-Bike Forgerd Crankset; 165mm for all sizes |
| CHAIN | Shimano LG500 |
| CASSETTE | Shimano LG400-9; 11-46; 9 speed |
| PEDALS | VP VPE-891 |
| HANDLEBAR | MERIDA EXPERT; material: aluminium; 680mm width; 15mm rise |
| STEM | MERIDA EXPERT TK III alum; 31.8mm diam; S/M- 70mm L/XL -90mmS/M- 70mm L/XL -90mm |
| HEADSET | Acros ICR MERIDA INTEGRATED neck w/ Blocklock |
| SEATPOST | MERIDA EXPERT CC; aluminium; 34.9mm; 0mm setback |
| SADDLE | MERIDA EXPERT TK II; 24% recycled material V-mount |
| HUBS | Shimano TC500 15x110mm 32 SPH CL front; Shimano TC500 12x148mm 32 SPH CL rear |
| RIMS | MERIDA COMP TR II; aluminium; 28mm; Tubeless ready (tape and valves not included); 29" |
| REAR AXLE | MERIDA EXPERT TR including removeable lever, 6/4mm allen key |
| TYRE FRONT | Maxxis Rekon; 29x2.4"; wire |
| TYRE REAR | Maxxis Rekon; 29x2.4"; wire |
| LIGHT FRONT | Lezyne Hecto StVZO E350+; Reverse MERIDA Custom Mount |
| LIGHT REAR | Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
| OTHER | Abus 4650 XL frame lock; Mini chainguide; MERIDA MIK HD Carrier; kickstand included |
