| FRAME | ONE-FORTY LITE III; 143 STR 29"; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK | Marzocchi Bomber Air; Air; platform |
| FORK | Marzocchi Z1; Air; 150 STR; Tapered; 44mm fork offset; 29.5x2.6" max. WHS |
| BRAKE - FRONT | Sram DB8 stealth; 4 piston |
| BRAKE - REAR | Sram DB8 stealth; 4 piston |
| ROTOR - FRONT | Sram CenterLine; 200mm |
| ROTOR - REAR | Sram CenterLine; 200mm |
| CHAIN | Sram SX Eagle |
| CHAINGUARD | |
| CHAINWHEEL | Sram Eagle S1000 Eagle; 32 ATC |
| CRANK/SIZE | 170 mm for all sizes |
| BB SET | Sram BB DUB BSA 73 MTB WIDE |
| DERA - FRONT | |
| DERA - REAR | Sram NX Eagle |
| FREEWHEEL | Sram PG-1210 Eagle; 11-50 ATC; 12 GER |
| PEDAL | |
| GRIP | MERIDA EXPERT EC |
| H-BAR | MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| H-B STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| H-STEM/SIZE | 40 mm |
| HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB - REAR | Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE - REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA EXPERT TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); 29" |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA TEAM TR II; 34.9 DSP; 10 SSB; all sizes 30-230 SPT |
| SHIFTER - FRONT | |
| SHIFTER - REAR | Sram NX |
| TIRE - FRONT | Maxxis Minion DHF; 29x2.5"; fold; TR EXO 3C MaxxTera |
| TIRE - REAR | Maxxis Dissector; 29x2.4"; fold; TR EXO+ MaxxTerra |
| BOTTLE CAGE | |
| E-SHIFT PARTS-1 | |
| OTHER 1 | Front Brake Adapter PM 180mm to 200mm rotor |
| OTHER 2 | Velcro strap & Tube Base Mount LITE |
| OTHER 3 | |
| OTHER 4 | |
| OTHER 5 | MERIDA Multitool with saddlebox |
