25 SCULTURA 7000

$6,499.00 (Inc GST)
LOW STOCK
Code: MERE250125

Select colour
Select Size


Share this page
Frame Name SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V
Frame Size Name 3XS XXS XS S M L XL
Tyre Sizes 28" 28" 28" 28" 28" 28" 28"
Frame Size Inch
ST  seat tube [mm] 400 435 458 481 501 521 550
Ste Seat Tubes Effective Mm
STA  seat tube actual [mm]
TT  top tube [mm] 505 520 535 545 560 575 590
CS  chain stay length [mm] 408 408 408 408 408 408 408
HTA  head tube angle [°] 70.5 70.5 72 72.5 73.5 73.5 74
STA  seat tube angle [°] 75.5 74.5 74 74 73.5 73 73
Stae Seat Tube Angle Effective Deg
Staa Seat Tube Angle Actual Deg
BD  bottom bracket drop [mm] 70 70 70 66 66 66 66
HT  head tube [mm] 100 105 112 128 140 155 176
FL  fork length [mm] 385 385 385 385 385 385 385
FO  fork offset [mm]
R  reach [mm] 373 377 383 390 395 400 409
S  stack [mm] 512 517 529 542 557 571 593
WB  wheel base [mm] 979 985 982 989 990 1000 1010
SH  stand over height [mm] 700 721 745 765 782 800 823
FRAME SCULTURA CF3 V; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; Pressfit 86,5
FORK SCULTURA CF3 disc; MAT carbon; 700x30C max. WHS
BRAKE LEVER Sram ED Rival eTap AXS
BRAKE - FRONT Sram ED Rival eTap AXS; Hydraulic disc
BRAKE - REAR Sram ED Rival eTap AXS; Hydraulic disc
ROTOR - FRONT Sram DB ROTOR CENTERLOCK PACELINE; 160mm
ROTOR - REAR Sram DB ROTOR CENTERLOCK PACELINE; 160mm
C-HOUSING
CHAIN SRAM Rival 12s
CHAINWHEEL Sram Rival eTap AXS ; 48-35 ATC; Power Meter
CRANK/SIZE 165 mm-3S/XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL
BB SET Sram Pressfit Dub, Presfit 86.5
DERAILLEUR - FRONT Sram Rival eTap AXS
DERAILLEUR - REAR Sram Rival eTap AXS; SS
FREEWHEEL Sram CS XG 1250 D1; 10-36 ATC; 12 GER
PEDAL
GRIP MERIDA ROAD Expert
HANDLEBAR SL-K Compact; MAT carbon; 380mm (3S-XXS-XS-S); 400mm (M-L-XL)
H-B STEM EXPERT SL 2PII; MAT aluminium; -9 ASD
H-STEM/SIZE 90mm-3S/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL
HUB - FRONT
HUB - REAR
AXLE - FRONT MERIDA EXPERT SL
AXLE - REAR MERIDA EXPERT SL; including removable lever; 6/4mm allen key
RIM VISION SC30 DB; 100x12 WHF; 142x12 WHR; 19 IWR; 33 HRI; Centerlock; MAT carbon
SADDLE MERIDA EXPERT SL; 6% recycled and 23% nature material; V-mount; incl. MERIDA minitool
SEAT CLAMP MERIDA EXPERT
SEAT POST MERIDA TEAM SL; 27.2 DSP; 15 SSB; Carbon; S-Flex
SHIFTER - FRONT Sram Rival eTAP AXS HRD
SHIFTER - REAR Sram Rival eTAP AXS HRD
TYRE - FRONT Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready
TYRE - REAR Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready
E-SHIFT PARTS-2
E-SHIFT PARTS-3
OTHER 5 MERIDA Multitool with saddlebox
Frame Name SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V SCULTURA CF3 V
Frame Size Name 3XS XXS XS S M L XL
Tyre Sizes 28" 28" 28" 28" 28" 28" 28"
Frame Size Inch
ST  seat tube [mm] 400 435 458 481 501 521 550
Ste Seat Tubes Effective Mm
STA  seat tube actual [mm]
TT  top tube [mm] 505 520 535 545 560 575 590
CS  chain stay length [mm] 408 408 408 408 408 408 408
HTA  head tube angle [°] 70.5 70.5 72 72.5 73.5 73.5 74
STA  seat tube angle [°] 75.5 74.5 74 74 73.5 73 73
Stae Seat Tube Angle Effective Deg
Staa Seat Tube Angle Actual Deg
BD  bottom bracket drop [mm] 70 70 70 66 66 66 66
HT  head tube [mm] 100 105 112 128 140 155 176
FL  fork length [mm] 385 385 385 385 385 385 385
FO  fork offset [mm]
R  reach [mm] 373 377 383 390 395 400 409
S  stack [mm] 512 517 529 542 557 571 593
WB  wheel base [mm] 979 985 982 989 990 1000 1010
SH  stand over height [mm] 700 721 745 765 782 800 823
